LLS-OP-W30A
LED seamless splicing contour linear light features a simple appearance and supports seamless connection. The lamp body adopts a bottom cable concealment design. The stainless steel bottom mounting spring clips provide excellent anti-loosening performance, and the spacing of the fixed spring clips can be adjusted horizontally for flexible installation. Both curved and square light-emitting covers are available to suit different scenes and effect requirements.
2200K
2700K
3000K
3500K
4000K
6500K
RGB
RGBW
150°
| Model | Length | Power(Max) | Colours Lumen | Package |
|---|---|---|---|---|
| LLS-OP-W30A-L6 | L615mm | 12W |
2700K3000K 480lm
4000K5700K
RGBW 300lm
|
0.58±5%Kg 40Units/Ctn 125.5*32*23CM |
| LLS-OP-W30A-L12 | L1220mm | 24W |
2700K3000K 960lm
4000K5700K
RGBW 600lm
|
1.16±5%Kg 20 Units/Ctn 125.5*32*23CM |
Advantages
Sturdy Construction
The lampshade is made of high-quality PC diffusive material, which isUV-resistant and anti-yellowing. It allows light to pass through but not tothe point, emits light evenly and has high luminous efficiency. (Squarelampshades can be customized.)
Full-structure waterproofing
excellent waterproofing effect, seamlessconnection, and uniform light effect.;
Flexible installation structure
Spring clip installation solution, suitable for installation in narrow slit positions.
Sturdy Construction
The lamp body is made of 6063 aluminum material, with an anti-oxidation surface treatment, featuring high heat dissipation andanti-corrosion performance
Control Flexibility
Go the distance and use your favourlite control protocols, including DMX/RDM,and remote control
3-Year Warranty
Standard 3-year warranty for completeassembly.
End cap
Signal input cable
Adapter cable
Y-type cable
End cap
