YXYSW4 |
 |
 |
| High wattage from 400W to 1200WLight efficiency up to 140lm/WHigh strength polycarbonate lens, optical lighting distribution: 10°/ 25°/ 45°/ 60°/ 90Integrated die casting heat sink: Excellent thermal management & compact structureDie-casting aluminum arm &bracket: Anti-typhoon 17 & high corrosion resistance for coastal areaIntegrated breather valve: Balance the internal & external temperature and humidityTop brand LED chip and driver, ensure the product quality and lifetimeIngress protection:lP66 waterproofDouble surge protection: Driver & extra 10KV SPD | |
Model Configuration Table:
|
Model No. |
YXYSW4-D400W |
YXYSW4-D500W |
YXYSW4-D600W |
YXYSW4-D700W |
YXYSW4-D800W |
YXYSW4-D900W |
|
Power |
400W |
500W |
600W |
700W |
800W |
900W |
|
Input Voltage |
AC100-277V;50/60Hz |
|||||
|
Lumen EFF |
150LM/W(±5%) |
|||||
|
LED Brand |
LUMILEDS 3030/OSRAM 3737 |
|||||
|
Driver Brand |
MEANWELL/ SOSEN /INVENTRONICS |
|||||
|
CCT |
3000K/4000K/5000K/5700K/6500K |
|||||
|
CRI |
Ra>80(70,90 Optional) |
|||||
|
PF |
0.95 |
|||||
|
Beam Angle |
10/25/45/60/90 |
|||||
|
IP Rating |
IP66 |
|||||
|
IK Rating |
IK08 |
|||||
|
Warranty |
5 Years |
|||||
|
Life Span |
50,000Hrs |
|||||
|
Working Temperature |
-35C-+50C |
|||||
|
Dimmension(mm) |
493*439*421mm |
651*586*511mm |
||||
|
Certifcation |
UL/ETL/CQC/CB/CE/ENEC/SAAFCC/RoHS |
|||||
